Product description
1. It can capture one single channel HD or SDI video signals. 2. The input and output video signal can reach 1080p/60 Hz. 3. It is compatible with UVC video capture and YUV 422 video output. 4. The UAC is compatible with HDMI audio capture and audio output, Support HDMI input HDMI output. 5. It doesnÆt need to install a driver, and it is truly PnP. 6. It is compatible with Windows 7, 8, 10, Linux, OS X (Mac) operating systems. 7. Size: 99.6x70x24mm (L/W/H, mm). 8. USB3.0, 360MB/s transmit bandwidth compatible with USB 2.0. 9. The process of video and audio is done by the dongle and will requires little CPU power. 10. It can automatically detect the input video formats and it will adjust to the set output size and frame rate automatically. 11. It supports the image adjustment features, like brightness, contrast, hue and saturation. 12. Multiple dongles can be used on one PC. 13. Firmware can be updated through USB port. 14. Auto detect input video format 1920x1080, 1920x960, 1680x1050, 1280x720, 1024x768, 960x540, 850x480,720x576, 720x540, 720x480, 720x404, 704x576, 640x480, 640x360. You can use any 3rd party software to capture or stream your video source: Adobe Flash Media Live Encoder (Windows) OBS Studio (Windows,Linux,OS X) VLC (Windows, Linux) Potplayer (Windows ) Wirecast (Windows OS X) Quicktime (OS X) and etc. Pacakge: 1 x Capture Dongle 1 x USB Cable 1 x User Manual
