Product description
Specification: Model: USB4KCAM01H-CFV(5-50) Sensor: 1/2.8" CMOS IMX415 Max Resolution: 3840(H)*2160(V) Sensitivity: 0.65V/lux-sec@550nm Pixel Size: 1.45mx1.45m Video Compression: MJPEG/ YUY2(YUYV) / H.264 / Resolution & Frame Rate: 3840x2160 MJPEG 30fps/ H.264 30fps/ 2560x1440 MJPEG 30fps/ H.264 30fps/ 1920x1080 MJPEG 30fps/ H.264 30fps/ YUY2 5fps 1280x720 MJPEG 30fps/ H.264 30fps/ YUY2 10fps 1024x576 MJPEG 30fps/ H.264 30fps/ / YUY2 15fps 960x540 MJPEG 30fps/ H.264 30fps/ YUY2 15fps 640x480 MJPEG 30fps/ H.264 30fps/ / YUY2 30fps 640x360 MJPEG 30fps/ H.264 30fps// YUY2 30fps Central Definition: 1000LW/PH(Center) S/N Ratio: 30dB Min illumination: 0.2Lux Shutter Type: ElectronicRollingShutter/FrameExposure Connecting Port Type: USB 2.0 Interface &HDMI v1.4 Interface AEC: Support, AWB: Support, AGC: Support Adjustable Parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Compensation, Exposure Lens Parameter: CS 5-50mm lens Power Supply & Interface: USB Type-C Power Supply, Type-C & HDMI Display Simultaneous Operating Voltage: DC5V Working Current: 480-500mA Storage Temperature: -20Cto85C Working Temperature: -10Cto70C USB Cable: 2 pieces cables (1pcs 1.2m cable with Type-C port, 1pcs 1.5m cable with HDMI port) Operating System Request: Win7/Win8/Win9/Win10/Win11 etc. LinuxwithUVC MAC-OSX10.4.8orlater, Android5.x or above.
Technical specifications
| SKU | PIB0CGWMS79Y |
|---|---|
| Sensor Type | CMOS |
| Connectivity Technology | HDMI, USB |
| Color | 5-50mm 10X Zoom Lens |
| Special Feature | 5-50mm manual variable focus lens, 4K USB & HDMI camera, H.264/MJPEG/YUY2 optional, simultaneous output, 4k camera with UVC for computer, laptop, pc, mini size, light weight |
| Photo Sensor Size | 1/2.8inch |
| Water Resistance Level | Not Water Resistant |
| Image stabilization | false |
| Form Factor | Compact |
| Style Name | 10X Optical Zoom, USB HDMI Dual Output, H.264, 2X Optical Zoom, 4K Ultra HD 30FPS, |
| Operating System | Win7/Win8/Win9/Win10/Win11 etc. Linux with UVC MAC-OSX10.4.8 or later Android 5.x or above |
