Product description
Main frequency 480MHz On chip 2M Flash, 1M SRAM External expansion QSPI driver W25Q64 External expansion of 16 bit wide 32MB SDRAM 1 reset button 1 BOOT button 1 user LED 1 Type C interface Reserve SWD and serial port 97 IO ports with pin arrangement and half hole lead out (Some IO ports are occupied by the core board, such as LCD pins) Working environment temperature -40~85 C One click entry into ISP mode without pressing the reset button, making it easy to download programs using USB Debug Interface SWD and USART1 Type C interface Support USB download program STM32H743IIT6 V version chip, with a main frequency of 480M SDRAM 16 bits wide, 32M bytes LCD interface RGB888 24 bit color 8M bytes W25Q64 Using QSPI driver to provide MDK download algorithm.
Technical specifications
| SKU | PIB0F28RDHB6 |
|---|---|
| RAM Memory Installed | 1 MB |
| Memory Storage Capacity | 32 MB |
| Connectivity Technology | SPI, UART, USB |
| Operating System | FreeRTOS, Linux |
| Compatible Devices | Type C interface compatible devices, SWD and serial port compatible devices |
| Processor Count | 1 |
| Total Usb Ports | 1 |
