Specifications & Details
| SKU | PIB0C2GMHLB2 |
|---|---|
| Product Dimensions | 5.5 x 3.5 x 1.1 inches |
| Item Weight | 0.068 kgs |
| Item model number | VG-RTL8111H-S |
| Manufacturer | Vogzone |
Product description
RTL8111H-1G-1T-X1 E1G42ET-1G-2T-X1 I350-T4V2-1G-4T-X4 RTL8125B-2.5-1T-X1 X550-10G-1T-X4 X550-10G-2T-X4
Buying Options
Buying Options
Buying Options
Buying Options
Buying Options
Buying Options
Customer Reviews
249
29
249
249
249
249
Controller Realtek RTL8111H Intel 82575/82576 Intel I350AM4 Realtek RTL8125B Intel ELX550AT Intel ELX550AT2
Port Configure RJ45(x1) RJ45(x2) RJ45(x4) RJ45(x1) RJ45(x1) RJ45(x2)
Data Rate / Port 10M/100M/1000M/s 10M/100M/1000M/s 10M/100M/1000M/s 10M/100M/1000M/2.5GbE/s 10 GbE/5 GbE/2.5 GbE/1 GbE/s 10 GbE/5 GbE/2.5 GbE/1 GbE/s
PCle PCIe 1.1 X1 PCIe 2.1 X1 PCIe 2.1 X4 PCIE x 1 PCIe 3.0 X4 PCIe 3.0 X4
Jumbo Frames Yes Yes, Up to 9.5KB Yes, Up to 9.5KB Yes Yes Yes
Operating Systems Windows/Linux/MAC OS/DOS; Centos/RHEL/Ubuntu/Debian/DSM/OpenWrt/PFSense/OPNSerse/IKUAI; VMWare ESXi 5.x and 6.x/Proxmox/unRaid Windows 7/8/10? Windows Server 2008/2012/2016/2019? Centos/RHEL 6/7/8? Ubuntu 16/18/19/20? Debian 9/10/11? FreeBSD 10/11/12? Vmware Esxi 5/6? SLSE 11/12? Windows XP Windows7/8/10 , Windows Server 2008/2012/2016/2019 , Centos/RHEL 6/7/8 , Ubuntu 16/18/19/20 , Debian 9/10/11 , FreeBSD 10/11/12 , Vmware Esxi 5/6/7 , SLSE 11/12 Windows ME/98SE/2000/XP, Win7 / Win8 / Win10 / Vista / Sever 2003/2008 / 2012 /2016/ Linux / DOS/MAC OS Windows 7/8/10; Windows Server 2008/2012/2016/2019; Centos/RHEL 6/7/8; Ubuntu 16/18/19/20; Debain 9/10/11; FreeBSD 10/11/12; Vmware Esxi 6/7; SLSE 11/12 Windows 7/8/10; Windows Server 2008/2012/2016/2019; Centos/RHEL 6/7/8; Ubuntu 16/18/19/20; Debain 9/10/11; FreeBSD 10/11/12; Vmware Esxi 6/7;SLSE 11/12
Un-supported VMware ESXi 7.0 or above Vmware Esxi 7.0, Mac OS, Bypass Mode Mac OS, Bypass Mode ESXI 7.0 Mac OS Mac OS
Data Rate 10/100/1000Mbps.
Supports Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az-2010,IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.1Q VLAN tagging, Full Duplex flow control (IEEE 802.3x)
OS Compatibility Windows/Linux/MAC OS/DOS; Centos/RHEL/Ubuntu/Debian/DSM/OpenWrt/PFSense/OPNSerse/IKUAI; VMWare ESXi 5.x and 6.x/Proxmox/unRaid. (Does not support VMware ESXi 7.0 or above)
Certification FCC, CE, RoHS
Single RJ45 port 1G network card, data rate per port:10/100/1000Mbps.
Equipped with original Realtek RTL8111H Chip which supports WOL, PXE, Jumbo Frame to 9K byte.
With standard and low-profile brackets in the package, this adapter is Suitable for most computer case installations.
Compatible with PCIe X1/X2/X4/X8/X16.
Not Compatible with PCI.
The NIC background has a driver QR code and a download connection sticker. Easy to download the driver.
Support Wake-On-LAN and RealWow Technology (remote wake-up), remotely power on/off your computer with WOL, good for centralized management.
