Specifications & Details
| SKU | PIB01N3YSBMY |
|---|---|
| Product Dimensions | 0.01 x 0.01 x 0.01 inches |
| Item Weight | 0.181 kgs |
| Item model number | X520-DA1-Intel |
| Is Discontinued By Manufacturer | No |
| Manufacturer | ipolex |
Product description
ipolex Network Card Product List
X520-10G-1S-X8
Buying Options
X520-10G-2S-X8
Buying Options
I210-1G-1S-X1
Buying Options
57810-10G-2S-X8
Buying Options
X710-10G-2S-X8
Buying Options
XL710-10G-4S-X8
Buying Options
X540-10G-2T-X8
Buying Options
Customer Reviews
602
602
602
602
602
602
602
Replacement for
X520-DA1 X520-DA2 I210-1S BCM57810S X710-DA2 X710-DA4 X540-T2
Controller
82599EN 82599ES I210AS Broadcom 57810S X710-BM2 XL710-BM1 X540-AT2
Port Configuration
(1x) SFP+ (2x) SFP+ (1x) SFP (2x) SFP+ (2x) SFP+ (4x) SFP+ (2x) RJ-45
System Interface Type
PCIe X8 PCIe X8 PCIe X1 PCIe X8 PCIe X8 PCIe X8 PCIe X8
Data Rate Per Port
1/10 GbE 1/10 GbE 1 GbE 1/10 GbE 1/10 GbE 1/10 GbE 100Mb/1GbE/10GbE
WOL
? ? ? ? ? ? ?
SR-IOV
? ? ? ? ? ? ?
PXE
? ? ? ? ? ? ?
Jumbo Frames
Yes , up to 15.5KB Yes , up to 15.5KB Yes , up to 9.5KB Yes Yes , up to 9.5KB Yes , up to 9.5KB Yes , up to 15.5KB
Operating Systems
Windows, Windows Server, etc Windows, Windows Server, etc Windows, Windows Server, etc Windows, Windows Server, etc Windows, Windows Server, etc Windows, Windows Server, etc Windows, Windows Server, etc
Unsupported Note
Mac OS Bypass Mode Mac OS Bypass Mode Windows XP Mac OS Bypass Mode Mac OS Bypass Mode Mac OS Bypass Mode Mac OS Bypass Mode Mac OS Bypass Mode
Windows 10 Teaming
? ? ? ? ? ? ?
