Product description
Sensor S5KGM1ST04-FG9br Max. Resolution 8000 (H) 6000 (V)br Lens Size 12 inch (43)br Compression Format MJPEG YUV2 (YUYV)br Resolution Frame Ratebr 8000x6000 5fps MJPEG 4000x3000 15fps MJPEGbr 3840x2160 30fps MJPEG 1920x1080 30fps MJPEGbr 1280x720 30fps MJPEGbr Surface Mount Technology SMTbr Focus Speed Fast About 200msbr Central Definition 1000LWPH (Center)br SN Ratio 36dBbr Dynamic Range 82dBbr Sensitivity 1.4Vlux-sec550nmbr Min illumination 0.3luxbr Shutter Type Electronic rolling shutterbr Connecting Port Type USB2.0 High Speedbr AEC AWB Supportbr Adjustable Parameters Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,White balance, Exposurebr Lens Parameter Size 12, DFOV About 82 degree, HFOV About 70 degree, Mount M8.15 P0.35br Power Supply USB BUS POWER 4P-2.0mm Socketbr Operating Voltage DC5Vbr Working Current 550Ma- 610mAbr Board Size Double-deck, 38mm 38mmbr Storage Temperature -20C to 80Cbr Working Temperature 0C to 70Cbr USB Cable 1mbr Operating System Requestbr Win XPVistaWin7Win8 Win10 Win11 etc.br Linux with UVC (above linux-2.6.26)br MAC-OS X 10.4.8 or laterAndroid 4.0 or above with UVC
Technical specifications
| SKU | PIB0C54VQKMS |
|---|---|
| Sensor Type | CMOS |
| Connectivity Technology | USB |
| Color | Black |
| Features | 200ms High-speed Auto Focus Function, 48MP 8K 4K 30FPS, HFOV 70, DFOV 82, No distortion lens |
| Photo Sensor Size | 1/2 inch (43) |
| Water Resistance Level | Not Water Resistant |
| Has Image Stabilization | No |
| Form Factor | Compact |
| Item Weight | 0.100 kgs |
| Style Name | 48MP01 |
| Item Dimensions D x W x H | 1.5"D x 1.5"W x 1.5"H |
| Operating System | Win XP/Vista/Win7/Win8 / Win10/ Win11 etc. Linux with UVC (above linux-2.6.26). MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC |
